24M1N5500Z/69
Gaming Monitor 24M1N5500Z Quad HD gaming monitor
This Philips gaming monitor delivers crystal-clear visuals and smooth gameplay. Sync technology, rapid 165Hz refresh rate with HDR create a polished and lifelike experience.

LowBlue mode and Flicker-free easy-on-the eyes viewing

SmartErgoBase enables people-friendly ergonomic adjustments

EasySelect menu toggle key for quick on-screen menu access

SmartImage HDR gives optimal viewing from your HDR content

IPS LED wide view technology for image and color accuracy

Crystalclear images with Quad HD 2560 x 1440 pixels

165Hz refresh rates for ultra-smooth, brilliant images

Low input lag reduces time delay between devices to monitor

1ms (MPRT) fast response for crisp image and smooth gameplay

Certified NVIDIA® G-SYNC® compatible for smooth fast gaming

AMD FreeSync™ Premium; tear free, stutter free, fluid gaming
Specifications
- ColorBlack
- FinishTextured
- Regulatory ApprovalsCB; CE Mark; FCC Class B; ICES-003
- Sync InputSeparate Sync
- Audio (In/Out)Audio out
- HDCPHDCP 1.4 (HDMI / DisplayPort) / HDCP 2.2 (HDMI / DisplayPort)
- Signal InputHDMI 2.0 x 2, DisplayPort 1.4 x 2
- User conveniencePower On/Off; Menu/OK; Input/Up; Game Settings/Down; SmartImage game/Back
- OSD LanguagesBrazil Portuguese; Czech; Dutch; English; Finnish; French; German; Greek; Hungarian; Italian; Japanese; Korean; Polish; Portuguese; Russian; Spanish; Simplified Chinese; Swedish; Turkish; Traditional Chinese; Ukrainian
- Other convenienceKensington lock; VESA mount (100x100mm)
- Plug & Play CompatibilityDDC/CI; Mac OS X; sRGB; Windows 11 / 10 / 8.1 / 8 / 7
- Product with stand(max height)540 x 513 x 213 mm
- Product without stand (mm)540 x 321 x 43 mm
- Packaging in mm (WxHxD)600 x 526 x 164 mm
- Temperature range (operation)0°C to 40 °C
- Temperature range (storage)-20°C to 60 °C
- Relative humidity20%-80 %
- AltitudeOperation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
- MTBF50,000 (Excluded backlight)
- LCD panel typeIPS technology
- Backlight typeW-LED system
- Panel Size23.8 inch / 60.5 cm
- Effective viewing area526.08 (H) x 295.92 (V)
- Display Screen CoatingAnti-Glare, 3H, Haze 25%
- Aspect ratio16:9
- Response time (typical)1 ms (Gray to Gray)*
- Brightness350 cd/m²
- Contrast ratio (typical)1000:1
- Pixel pitch0.2055 x 0.2055 mm
- Viewing angle178º (H) / 178º (V); @ C/R > 10
- Display colors16.7 M
- Scanning FrequencyHDMI: 30 - 230 kHz (H) / 48 - 144 Hz (V); DP: 30 - 250 kHz (H) / 48 - 165 Hz (V)
- sRGBYes
- Picture enhancementSmartImage game
- Pixel Density123.41 PPI
- Flicker-freeYes
- LowBlue ModeYes
- EasyReadYes
- Adaptive syncYes
- AMD FreeSync™ technologypremium
- Maximum resolutionHDMI: 2560 x 1440 @ 144 Hz, DP: 2560 x 1440 @ 165 Hz*
- Low Input LagYes
- MPRT1 ms
- G-SYNCYes
- SmartContrastMega Infinity DCR
- Color gamut (typical)NTSC 102.5%*, sRGB 108.7%*
- HDRHDR 10 supported
- On mode26.4 W (typ.)
- Standby mode0.5 W (typ.)
- Off mode0.3 W (typ.)
- Power LED indicatorOperation - White; Standby mode- White (blinking)
- Power supplyExternal; 100-240VAC, 50-60Hz
- Environmental and energyRoHS
- Recyclable packaging material100 %
- Specific SubstancesMercury free; PVC / BFR free housing
- Height adjustment130 mm
- Tilt-5/20 degree
- Pivot-/+ 90 degree
- Swivel-/+ 45 degree
- Product with stand (kg)4.30 kg
- Product without stand (kg)3.00 kg
- Product with packaging (kg)6.25 kg
Disclaimers
- * "IPS" word mark / trademark and related patents on technologies belong to their respective owners.
- * The maximum resolution works for DP input only.
- * For best output performance, please always ensure that your graphic card is capable of achieving the maximum resolution and refresh rate of this Philips display.
- * Response time value equal to SmartResponse
- * MPRT is to adjust brightness for blur reduction, so cannot adjust brightness while MPRT is turned on. To reduce motion blur, LED backlight will strobe synchronously with screen refresh, which may cause noticeable brightness change.
- * MPRT is gaming-optimized mode. Turn on MPRT may cause noticeable screen flickering. It is recommended to turn off when you are not using the gaming function.
- * NTSC Area based on CIE1976
- * sRGB Area based on CIE1931
- * 2020 Advanced Micro Devices, Inc. All rights reserved. AMD, the AMD Arrow logo, AMD FreeSync™ and combinations thereof are trademarks of Advanced Micro Devices, Inc. Other product names used in this publication are for identification purposes only and may be trademarks of their respective companies.
- * NVIDIA® G-SYNC® support interface: DisplayPort
- * Make sure to update NVIDIA® G-SYNC® driver to the latest version, see more information on NVIDIA website: https://www.nvidia.com/
- * Make sure your graphic card supports NVIDIA® G-SYNC®
- * The monitor may look different from feature images.
